Visually demonstrating your home design is an essebtial component in the early stages of design. A home design diagram provides an immediate ‘visual’ representation of spaces within the proposed building, on the proposed site. This visual relationship of external and internal areas enables you to keep on-track working towards a well design home.
A simple site plan with boundary lines and any dominating elements should be drawn alongside the schedule of areas. The plan outlines the building spaces in relation to that available on site. Any challenges between the clients brief and local council requirements can be seen and addressed. The shape of the ‘boxes’ representing the dwelling spaces is irrelevant – they are only indicative for their comparative size.
